1500 mm Disk Blade Foil Slicing Machine

1500 mm Disk Blade Foil Slicing Machine

Kadromak Machine ECT 1500 AT Disk Blade Foil Slicing Machine is a high-performance slicing machine designed to cut PVC, PP, micro-laminates, and certain paper foils precisely and effectively. This machine slices foils flawlessly thanks to its upper-lower rotary blade system and provides high efficiency in industrial production processes.

Advanced Cutting Capacity and Flexibility

One of the most striking features of the ECT 1500 AT is its ability to operate at cutting speeds of up to 70 meters per minute. This speed ensures high efficiency in production processes and allows for large-scale productions. The capacity to cut foils up to 1500 mm wide and 0.4 mm thick enables the machine to work with materials of different sizes and thicknesses. This flexibility makes it suitable for various industrial applications.

Powerful and Durable Design

The movement of the machine's rollers is provided by a dual motor and chain system, which increases the precision and reliability of the cutting process. Operating with a total power consumption of 4-5 kW, the ECT 1500 AT stands out with its energy efficiency while also delivering high performance. The machine can be equipped with an optional foil heater, providing additional advantages for certain applications.

Ease of Use and Optional Features

Kadromak ECT 1500 AT can be configured with both pneumatic and friction shafts. The pneumatic shaft system allows for quick and easy operation of the machine and offers flexibility during the production process. Equipped with a total of 10 blades, the machine is ideal for meeting various cutting needs.

The dimensions of the machine are compact, with a length of 2.3 meters, a width of 1.2 meters, and a height of 1 meter. This compact design saves space in the production area while also making the machine easy to install and maintain.

Advantages of Kadromak Machine ECT 1500 AT Disk Blade Foil Slicing Machine:

• High Cutting Speed: Operates at speeds of up to 70 meters per minute, ensuring high production efficiency.

• Wide Material Compatibility: Can cut PVC, PP, micro-laminates, and paper foils up to 1500 mm wide and 0.4 mm thick.

• Powerful Motor and Chain System: The dual motor and chain system provides a precise and reliable cutting process.

• Optional Foil Heater: Provides additional advantages for certain applications with the optional foil heater.

• Compact and User-Friendly Design: Saves space with its compact size, offering easy installation and maintenance.

Technical Specifications:

• Cutting Speed: 70 m/min

• Max Foil Width: 1500 mm

• Max Foil Thickness: 0.4 mm

• Number of Blades: 10 pcs.

• Total Power: 4-5 kW

• Machine Length: 2.3 m

• Machine Width: 1.2 m

• Machine Height: 1 m

• Shaft Type and Number: Pneumatic Shaft / 3 pcs.

Kadromak Machine ECT 1500 AT Disk Blade Foil Slicing Machine is an ideal solution for businesses seeking high efficiency, precise cutting, and flexibility. This machine is an excellent investment to enhance your performance in industrial production processes and reduce your costs.
