2000 Kg/Hour Compact Steam Generator
2000 Kg/Hour Compact Steam Generator
Universal Boiler KBJ 2000
GENERAL FEATURES
- Takes up little space and produces economical steam in a very short time.
- Manufactured according to heavy-duty conditions. Not easily affected by hard and turbid waters.
- Operates automatically and safely. Has sequential safety systems.
- Works without requiring excessive information, maintenance, and supervision.
- Proven itself with hundreds of examples operating in Turkey and abroad for years.
- It is a compact unit with a boiler, feed water pump, condensate tank, water filter, automatic water softening unit, and electrical panel.
DESIGN
- An ideal steam producer for hotels, laundries, garment and knitwear factories, feed industry, concrete curing, dry cleaning, beverage bottling industry, steam washing and cleaning, sock industry, and similar industrial facilities.
COMPONENTS
- Steam generator
- Boiler fittings
- Safety systems
- Feed water (condensate) tank and fittings
- Boiler feed pump and fittings
- Burner
- Automatic water softening device
- Water filter
- Electrical panel and installation
|
|
Steam Capacity (kg/h) |
Length Without Fittings L (mm) |
Length With Fittings L (mm) |
Width With Fittings E (mm) |
Height Without Fittings H (mm) |
Height With Fittings H (mm) |
Water Volume (lt) |
Chimney Diameter (mm) |
Approximate Weight (kg) |
Smoke Duct Resistance (mmSS) |
|
KBJ 2000 |
2,000 |
3,500 |
4,500 |
2,140 |
2,910 |
3,160 |
2,400 |
500 |
6,377 |
50
|
