20W UV Laser Marking Machine

About

It is a professional industrial UV laser marking machine developed for permanent marking of sensitive and heat-sensitive materials.
Thanks to the 355 nm DPSS-UV laser technology, it performs high-resolution marking on plastics, glass, electronic components, and medical products without damaging the surface.
With 20W laser power, it offers strong, stable, and efficient marking performance in high-speed production lines.
It can mark QR Codes, DataMatrix, barcodes, serial numbers, dates, logos, and variable data in real-time.
Thanks to the motorized and fully automatic focusing system, it quickly and accurately adapts to products at different heights.
Its industrial water-cooled structure provides long-lasting and stable working performance without interruption.
It can be easily integrated into production lines and automation systems with USB and External I/O connections.
The ergonomic control panel provides operators with a safe, practical, and fast usage opportunity.

Areas of Use

Electronic component production
PCB board production
Medical device production
Plastic packaging production
Cosmetic industry
Glass product marking
Cable and connector production
White goods industry
Laboratory equipment
Precision plastic parts
Automotive sub-industry
Promotional products

Technical Specifications

Feature	Value
Laser Technology	355 nm DPSS-UV Industrial Water-Cooled Laser
Laser Power	20 W
Marking Area	70×70 mm, 110×110 mm, 150×150 mm, 170×170 mm, 200×200 mm
Working Frequency	50 – 500 kHz
Marking Speed	Maximum 1,000 characters/sec*
Laser Pulse Duration	15 ns / 50 kHz
Total Weight	45 kg
Connections	USB, External I/O
Focusing System	Motorized and Fully Automatic Focusing
Control Unit	Laser Activation and Emergency Stop Buttons
Control Panel	Start, Stop, Up, Down, LED and Pointer Controls
Cooling System	Industrial Water-Cooled

*Marking speed may vary depending on character size and application conditions.

Highlighted Advantages

Marks without causing burns and deformation on sensitive surfaces.
Provides high efficiency in high-speed production lines thanks to 20W laser power.
Performs high-contrast and clear marking on plastics, glass, and electronic products.
Adapts to different product heights in seconds with motorized automatic focusing.
Supports QR Code, DataMatrix, barcode, and serial number applications.
Can be easily integrated with automation systems thanks to USB and External I/O connections.
Offers stable performance for long periods thanks to its industrial water-cooled system.
Reduces operating costs due to low maintenance needs and long laser life.

Why Should You Prefer the 20W UV Laser Marking Machine?

The 20W UV Laser Marking Machine is a professional marking solution developed for businesses with high production speeds. Thanks to its 20W laser power, it can perform high-quality marking in shorter cycle times compared to 5W, 10W, and 15W models. With UV laser technology, it achieves high-contrast marking on plastics, glass, electronics, and medical products without burning the surface. Its fully compatible structure with automation systems allows it to be safely used in Industry 4.0 production lines.

Frequently Asked Questions

What materials can the 20W UV laser be used on?

It can be safely used on glass, plastic, acrylic, silicone, electronic boards (PCB), ceramics, medical products, and many sensitive materials.

What is the advantage over the 15W model?

The 20W model can operate at higher production speeds due to its higher laser power, providing greater efficiency for businesses with intensive production.

Can it mark QR Codes and DataMatrix?

Yes. It can perform QR Code, DataMatrix, barcode, serial number, date, and logo applications with high precision.

Can it be connected to automation systems?

Yes. It can be easily integrated with ERP, MES, PLC, and other production automation systems thanks to USB and External I/O connections.

Does it have an automatic focusing system?

Yes. A motorized and programmable fully automatic focusing system is provided as standard.

Shipping and Delivery Information

The product is shipped in accordance with safe transport standards.
Installation, commissioning, and operator training are carried out by expert technical teams.
Production line integration and software support are provided.
After-sales technical service and spare parts support are offered.
It can be configured on a project basis according to different marking areas and laser power options.
