30W Fly Fiber Laser Marking Machine

About

This is an industrial Fiber Fly Laser Marking Machine developed for marking products in motion at high speed and without contact.
Thanks to the 30W Ytterbium (Yb) pulsed fiber laser technology, it performs high-contrast, permanent, and precise marking on metal and many engineering plastics.
It can perform uninterrupted marking on production lines at speeds of up to 200 meters per minute.
It can mark graphics, logos, QR Codes, DataMatrix, barcodes, serial numbers, lot numbers, dates, and shift information in real-time.
It offers high precision and clear marking quality thanks to high-speed galvo mirrors.
It provides easy use and fast programming with a touchscreen user interface.
It can work in integration with ERP, MES, and PLC systems thanks to UDP, TCP/IP, and RS232 communication protocols.
Its air-cooled structure offers low maintenance costs and a long working life.

Areas of Use

Automotive industry
Machine manufacturing
Metal processing
Electrical and electronic production
Cable and pipe production
Defense industry
Medical device manufacturing
Aerospace industry
Mold production
Advertising and promotional products
Jewelry and goldsmithing
Mass production lines

Technical Specifications

Feature	Value
Laser Technology	Ytterbium (Yb) Pulsed Fiber Laser
Laser Power	30 W
Marking Speed	Maximum 200 m/min
Lens Options	F63 (50×50 mm), F100 (70×70 mm), F210 (140×140 mm), F254 (175×175 mm), F330 (220×220 mm), F420 (300×300 mm)
Marking Content	Graphics, Logo, Symbol, Serial No, Lot No, Date, Time, Shift Code
Barcode Support	QR Code, DataMatrix, and 1D Barcodes
Font Type	Dot-based industrial font types
Communication	UDP, TCP/IP, RS232
Sensor Connections	Encoder and Product Sensor
Digital Input / Output	Start, Stop, Operator Lock, and Safety Inputs
Power Supply	110-240 VAC / 50-60 Hz
Power Consumption	0.70 kW
Cooling System	Air Cooled
Operating Temperature	5°C – 40°C
Humidity Range	%10 – %90

Highlighted Advantages

It can perform high-speed marking on production lines operating at up to 200 meters per minute.
Thanks to the 30W fiber laser power, it offers faster and more distinct marking performance compared to 20W models.
It can perform applications of graphics, logos, symbols, QR Codes, and DataMatrix with high precision.
It can automatically generate serial numbers, dates, times, lot numbers, and shift information.
Thanks to TCP/IP, UDP, and RS232 communication support, it can be easily integrated into ERP, MES, and PLC systems.
Its air-cooled structure provides low maintenance costs and long-lasting use.
It offers a user-friendly working experience with its touchscreen.
With different focus lenses, it has a wide application area from small parts to large products.

Why Should You Prefer the 30W Fly Fiber Laser Marking Machine?

The 30W Fly Fiber Laser Marking Machine is a professional marking solution developed for businesses with high-speed production, focusing on performance and efficiency. It performs clear, permanent, and readable marking at higher production speeds thanks to its 30W fiber laser power. The laser technology, which does not require ink or solvent, reduces operating costs while contributing to Industry 4.0 processes by working in full compliance with ERP and production automation systems. It is an ideal solution for businesses that require high quality on metal and technical plastic products.

Frequently Asked Questions

On which materials can the 30W Fiber Fly laser be used?

It can perform permanent marking on stainless steel, carbon steel, aluminum, copper, brass, titanium, galvanized, hard plastics, and many engineering materials.

Can it be used on moving production lines?

Yes. It can perform marking with high precision on production lines operating at up to 200 meters per minute.

Can it mark QR Codes and barcodes?

Yes. It supports QR Code, DataMatrix, and many 1D barcode standards.

Can it communicate with ERP and automation systems?

Yes. It can work in integration with ERP, MES, PLC, and production automation systems thanks to UDP, TCP/IP, and RS232 communication protocols.

Does it use consumables?

No. Permanent marking is done without using ink or solvent thanks to fiber laser technology.

Can different marking areas be used?

Yes. Different focus lenses can be used to create a marking area suitable for the application, ranging from 50×50 mm to 300×300 mm.

Shipping and Delivery Information

The product is shipped in accordance with safe transport standards.
Installation, commissioning, and production line integration are carried out by a specialized technical team.
Technical support is provided for software installation and automation connections.
After-sales technical service, maintenance, and spare parts support are provided.
It can be configured on a project basis according to different lens options and automation needs.
