50W Fly Fiber Laser Marking Machine

About

This is an industrial Fiber Fly Laser Marking Machine developed for marking products in motion at high speed and without contact.
Thanks to the 50W Ytterbium (Yb) pulsed fiber laser technology, it can perform high-speed, deep, and permanent marking on metal and technical plastic surfaces.
It offers uninterrupted marking performance on production lines of up to 200 meters per minute.
It can mark graphics, logos, QR Codes, DataMatrix, barcodes, serial numbers, lot numbers, dates, and shift information in real-time.
It provides high precision and clear marking quality thanks to high-speed galvo mirrors.
It offers easy use and fast programming with a touchscreen user interface.
It can work in integration with ERP, MES, and PLC systems thanks to UDP, TCP/IP, and RS232 communication protocols.
Its air-cooled structure allows for long-term use with low maintenance costs.

Areas of Use

Automotive industry
Machine manufacturing
Metal processing facilities
Electrical and electronic production
Cable and pipe production
Defense industry
Medical device manufacturing
Aerospace industry
Mold production
Advertising and promotional products
Jewelry and goldsmithing
Mass production lines

Technical Specifications

Feature	Value
Laser Technology	Ytterbium (Yb) Pulsed Fiber Laser
Laser Power	50 W
Marking Speed	Maximum 200 m/min
Lens Options	F63 (50×50 mm), F100 (70×70 mm), F210 (140×140 mm), F254 (175×175 mm), F330 (220×220 mm), F420 (300×300 mm)
Marking Content	Graphics, Logo, Symbol, Serial No, Lot No, Date, Time, Shift Code
Barcode Support	QR Code, DataMatrix, and 1D Barcodes
Font Type	Dot-based industrial font types
Communication	UDP, TCP/IP, RS232
Sensor Connections	Encoder and Product Sensor
Digital Input / Output	Start, Stop, Operator Lock, and Safety Inputs
Power Supply	110-240 VAC / 50-60 Hz
Power Consumption	0.70 kW
Cooling System	Air Cooled
Operating Temperature	5°C – 40°C
Humidity Range	%10 – %90

Highlighted Advantages

It can perform high-speed marking on production lines operating at up to 200 meters per minute.
Thanks to the 50W fiber laser power, it offers superior performance in deep engraving and high-contrast marking applications.
It can perform graphic, logo, symbol, QR Code, and DataMatrix applications with high precision.
It can automatically generate serial numbers, dates, times, lot numbers, and shift information.
Thanks to TCP/IP, UDP, and RS232 communication support, it easily integrates with ERP, MES, and PLC systems.
Its air-cooled structure provides low maintenance costs and long-lasting use.
It offers fast programming and easy use with its touchscreen.
It provides flexible marking solutions from small parts to large surfaces with different focus lenses.

Why Should You Prefer the 50W Fly Fiber Laser Marking Machine?

The 50W Fly Fiber Laser Marking Machine is a professional industrial marking solution developed for businesses with high production capacity. With its 50W laser power, it offers higher performance in deep marking, engraving, and high-speed production applications compared to 20W and 30W models. The fiber laser technology, which does not require ink or solvent, reduces operating costs, and its fully compatible structure with automation systems allows for easy integration into Industry 4.0 production processes.

Frequently Asked Questions

On which materials can the 50W Fiber Fly laser be used?

It can perform permanent marking on stainless steel, carbon steel, aluminum, copper, brass, titanium, galvanized, hard plastics, and many engineering materials.

Can it be used on moving production lines?

Yes. It can perform marking with high precision on production lines operating at up to 200 meters per minute.

Can it perform deep marking?

Yes. Thanks to the 50W laser power, successful results are obtained in deep engraving, high-contrast marking, and intensive production applications.

Can it mark QR Codes and barcodes?

Yes. It supports QR Code, DataMatrix, and many 1D barcode standards.

Can it communicate with ERP and automation systems?

Yes. It can work in integration with ERP, MES, PLC, and production automation systems thanks to UDP, TCP/IP, and RS232 communication protocols.

Does it use consumables?

No. Permanent marking is done without the use of ink or solvent thanks to fiber laser technology.

Shipping and Delivery Information

The product is shipped in accordance with safe transport standards.
Installation, commissioning, and production line integration are carried out by expert technical teams.
Technical support is provided for software installation and automation connections.
After-sales maintenance, technical service, and spare parts support are offered.
It can be configured on a project basis according to different lens options and automation needs.
