| Advertisement No: | #00254210 |
| Category: | Combined Scissors |
| Brand: | Cronosstech |
| Model Type: | KMH 55 |
| Product Type: | For Sale |
| Product Status: | New |
| Origin: | Turkey |
| Location: | İkitelli OSB Mah. / Başakşehir / İstanbul |
| Short Detail: | 1 Yıl Guaranteed |
| Sales Detail: | Negotiated |
| Delivery Status: | 45 Day |
Maximum thickness diameter: Ø 20 × 20 mm Diameter × thickness (Ø × t): Ø 40 × 10 mm Maximum diameter thickness: Ø 100 × 3 mm Stroke length: 60 mm Number of strokes: 25 Groove depth: 255 mm Working height: 1030 mm Round / Square: Ø 40 / 40 mm Vertical angle iron (90°): 120 × 120 × 12 mm Angled angle iron (45°): 70 × 10 mm Working height: 1130 mm Flat sheet: 200 × 20 mm Flat sheet: 300 × 15 mm Blade length: 317 mm Angled cut: 80 × 15 mm Working height: 900 mm Material thickness: 10 mm Width: 45 mm Depth: 90 mm Working height: 900 mm U–I profile blades (UPN–IPN): 120 × 58 mm T profile blades: 80 × 9 mm 100 × 100 × 10 mm Blade bending (max.): 250 × 12 mm Sheet bending (max.): 500 × 3 mm Jaw depth: 125 mm Sheet punching: Ø 38 × 8 mm Motor power: 5.5 kW Pressure: 55 tons Machine weight: 1520 kg Machine dimensions (W × D × H): 1500 × 950 × 1880 mm 2 separate hydraulic pistons and 2 separate foot controls allowing two people to work simultaneously Possibility of serial operation with adjustable piston stroke distance Central lubrication system Electric switchable rear support Working lamp On the same body, 5 separate workstations: Ø22 mm punch and die / standard hole punching Full round and full square cutting Angle iron cutting Blade and sheet cutting U-notchingKMH 55 – HYDRAULIC DOUBLE PISTON COMBINED SHEAR
STANDARD EQUIPMENT
PUNCHING MACHINE
FULL MATERIAL SHEAR
ANGLE IRON CUTTING SHEAR
SHEET METAL SHEAR (BLADE CUTTING)
NOTCHING
OPTIONAL EQUIPMENT
SPECIAL DIES
SPECIAL NOTCHING TOOL
V BENDING
PUNCH IN NOTCHING SECTION
TECHNICAL SPECIFICATIONS (KMH 55)
GENERAL EQUIPMENT AND STRUCTURE
