| Advertisement No: | #00218204 |
| Category: | Injection Machine |
| Brand: | İkaros Makine |
| Model Type: | 560T |
| Product Type: | For Sale |
| Product Status: | New |
| Origin: | Chinese |
| Location: | Topçular Mah. / Eyüp / İstanbul |
| Sales Detail: | Negotiated |
| Delivery Status: | Made to Order |
VİLTECH X Ikaros Machine 560T
560 Ton Plastic Injection Machine
Ikaros Machine 560T Technical Specifications:
DESCRIPTION
DESCRIPTION
UNIT
VT-560V7
CLAMPING UNIT
Clamping Force
Clamping Force
ton
560
Max. daylight
Max. daylight
mm
1750
Clamping Stroke
Clamping Stroke
mm
880
Clearance Between Tie Bars
Clearance Between Tie Bars
mm
860X840
Min Mould Dimension
Min Mould Dimension
Mm
600X588
Mould Thickness Range
Mould Thickness Range
mm
320-870
Ejector Force
Ejector Force
ton
16.6
Ejector stroke
Ejector stroke
mm
220
No. of Ejector Pins
No. of Ejector Pins
unit
21
System Pressure
System Pressure
MPa
17.5
INJECTION UNIT
International Specification
International Specification
3350
Screw diameter
Screw diameter
mm
76
84
92
Theoretical Shot Volume
Theoretical Shot Volume
cm3
1678
2050
2460
Shot Weight (PS)
Shot Weight (PS)
g
1527
1866
2238
Length/Diameter Ratio
Length/Diameter Ratio
L/D
22
20
20
Injection Pressure
Injection Pressure
M Pa
199
163
136
Injection Rate
Injection Rate
cm3/s
435
531
637
Injection Stroke
Injection Stroke
mm
370
Screw Speed
Screw Speed
RPm
155
GENERAL INFORMATION
Major Motor
Major Motor
kW
62
No. of Heater Zones
No. of Heater Zones
unit
5+1
Heater Input Power
Heater Input Power
kW
33/37
Oil Tank Capacity
Oil Tank Capacity
L
790
Net Weight
Net Weight
ton
24
Machine Dimension(L*W*H)
Machine Dimension(L*W*H)
M
8.55x1.82x2.45
