| Advertisement No: | #00218207 |
| Category: | Injection Machine |
| Brand: | İkaros Makine |
| Model Type: | 650T |
| Product Type: | For Sale |
| Product Status: | New |
| Origin: | Chinese |
| Location: | Topçular Mah. / Eyüp / İstanbul |
| Sales Detail: | Negotiated |
| Delivery Status: | Made to Order |
VİLTECH X Ikaros Machine 650T
650 Ton (62 kW) Plastic Injection Machine
Ikaros Machine 650T Technical Specifications:
DESCRIPTION
DESCRIPTION
UNIT
VT-650V7
CLAMPING UNIT
Clamping Force
Clamping Force
ton
650
Max. daylight
Max. daylight
mm
1840
Clamping Stroke
Clamping Stroke
mm
920
Clearance Between Tie Bars
Clearance Between Tie Bars
mm
930х930
Min Mould Dimension
Min Mould Dimension
Mm
675x665
Mould Thickness Range
Mould Thickness Range
mm
370-920
Ejector Force
Ejector Force
ton
18.2
Ejector stroke
Ejector stroke
mm
280
No. of Ejector Pins
No. of Ejector Pins
unit
21
System Pressure
System Pressure
MPa
17.5
INJECTION UNIT
International Specification
International Specification
5000
Screw diameter
Screw diameter
mm
84
92
100
Theoretical Shot Volume
Theoretical Shot Volume
cm3
2328
2792
3299
Shot Weight (PS)
Shot Weight (PS)
g
2118
2541
3002
Length/Diameter Ratio
Length/Diameter Ratio
L/D
22
20
20
Injection Pressure
Injection Pressure
M Pa
218
181
154
Injection Rate
Injection Rate
cm3/s
579
695
821
Injection Stroke
Injection Stroke
mm
420
Screw Speed
Screw Speed
RPm
164
GENERAL INFORMATION
Major Motor
Major Motor
kW
32+50
No. of Heater Zones
No. of Heater Zones
unit
5+1
Heater Input Power
Heater Input Power
kW
38/47
Oil Tank Capacity
Oil Tank Capacity
L
1000
Net Weight
Net Weight
ton
29.5
Machine Dimension(L*W*H)
Machine Dimension(L*W*H)
M
10.5x2.28x2.75
