| Advertisement No: | #00218187 |
| Category: | Injection Machine |
| Brand: | İkaros Makine |
| Model Type: | 90T |
| Product Type: | For Sale |
| Product Status: | New |
| Origin: | Chinese |
| Location: | Topçular Mah. / Eyüp / İstanbul |
| Sales Detail: | Negotiated |
| Delivery Status: | In stock |
Equipped with a high-performance servo system. The output power of the servo motor changes with the load without excessive energy loss. During pressure holding, it reduces the motor speed and energy consumption is extremely low. The motor does not operate during cooling, and energy consumption is zero. It increases injection accuracy while saving water and reducing noise. A true revolution in hydraulic injection machines. VT-V7, equipped with a high-response servo motor and internal gear pump system, reaches maximum output in just 0.05 seconds, significantly shortening the cycle time compared to traditional hydraulic injection machines and increasing production efficiency. The precision of the VT-V7 is superimposed on the precision of the internal gear pump, creating a closed loop thanks to the high-precision pressure feedback device. Injection repeatability significantly increases injection stability compared to traditional hydraulic machines, and qualified mold parts can reach up to 3%. VİLTECH X Ikaros Machine 90T
90 Ton Plastic Injection Machine
Drive Technology
High Response
High Repeatability
Ikaros Machine 90T Technical Specifications:
DESCRIPTION
DESCRIPTION
UNIT
VT-90V7
CLAMPING UNIT
Clamping Force
Clamping Force
ton
90
Max. daylight
Max. daylight
mm
700
Clamping Stroke
Clamping Stroke
mm
320
Clearance Between Tie Bars
Clearance Between Tie Bars
mm
360X360
Min Mould Dimension
Min Mould Dimension
Mm
252X252
Mould Thickness Range
Mould Thickness Range
mm
130-380
Ejector Force
Ejector Force
ton
3.4
Ejector stroke
Ejector stroke
mm
100
No. of Ejector Pins
No. of Ejector Pins
unit
5
System Pressure
System Pressure
MPa
17.5
INJECTION UNIT
International Specification
International Specification
360
Screw diameter
Screw diameter
mm
32
37
42
Theoretical Shot Volume
Theoretical Shot Volume
cm3
149
199
256
Shot Weight (PS)
Shot Weight (PS)
g
135
181
233
Length/Diameter Ratio
Length/Diameter Ratio
L/D
24.3
21.0
18.5
Injection Pressure
Injection Pressure
M Pa
239.3
179.0
138.9
Injection Rate
Injection Rate
cm3/s
112
150
193
Injection Stroke
Injection Stroke
mm
185
Screw Speed
Screw Speed
RPm
318
GENERAL INFORMATION
Major Motor
Major Motor
kW
16
No. of Heater Zones
No. of Heater Zones
unit
3+1
Heater Input Power
Heater Input Power
kW
8.1/10
Oil Tank Capacity
Oil Tank Capacity
L
175
Net Weight
Net Weight
ton
3.3
Machine Dimension(L*W*H)
Machine Dimension(L*W*H)
M
4.1x1.20x1 .7
