| Advertisement No: | #00079504 |
| Category: | Bed Edge Closing Machine |
| Brand: | Veysel Kütüklü |
| Model Type: | Nexus 3500 |
| Product Type: | For Sale |
| Product Status: | New |
| Origin: | Turkey |
| Location: | Yukarıdudullu Mah. / Ümraniye / İstanbul |
| Warranty Status: | 2 Yıl Guaranteed |
| Sales Detail: | Bank Transfer |
| Delivery Status: | In stock |
Production capacity of 250 pieces in 8 hours for each shift (bed edge closing) With its flexibility and performance, it has a large or small bed production capacity. High-quality machines that you can own at the most reasonable prices. The automatic bed turning feature reduces the operator's workload. The machine of every bed manufacturer's dream. VK Bed Machines has developed robust and high-speed bed edge closing machines to serve bed manufacturers for many years. The Nexus series bed edge closing machines are designed to facilitate the stitching process in bed edge closing for all types of beds thanks to their superior flexibility. With their ergonomic structures, they are produced to achieve high efficiency in the edge closing process. Nexus Series Outstanding Features of Nexus 3500 Nexus 3500 is designed to achieve the highest efficiency in edge closing operations with its ergonomic structure. With features like motorized conveyor belt, bed turning system, automatic stitch head adjustment, slowing down in corners, and easy height and speed adjustment, Nexus 3500 offers the best experience in stitching operations for all types of beds. Nexus 3500 has a simple design and ergonomic structure with the highest quality materials used in its details. Independent Operating Conveyor Belts + Two independent operating conveyor belts provide an uninterrupted stitching process + The conveyor belts and sewing machine operate in synchronization, allowing for extremely easy adjustment of stitching speed Simple Bed Turning Without Intervention + Thanks to the bed turning arms, beds are turned very easily + Automatic bed turning eliminates the need for the operator to turn the bed Smart Needle Cooling System + The smart cooling system allows the needle to be cooled with air during the stitching process User-Friendly Touch Screen + The user-friendly touch screen offers easy operation and control for the operator More Flexibility in Corners + Thanks to the automatic adjustment of the sewing machine position, it provides a simple stitching process in bed corners + The machine automatically slows down during the corner stitching process Perfect Stitching Process for All Types of Beds + Flexible design offers high efficiency even for heavy beds Nexus Series Outstanding Features of Nexus A 100 Nexus A100 has a durable design with quality materials used in every detail. Simple Edge Closing Process by Rotating Around the Bed + Supports the operator during the stitching process More Flexibility in Corners + Automatically slows down during the corner stitching process Easy Use with Foot Pedals + Three foot pedals provide convenience for the operator Adjustable Table Height + Table height can be easily adjusted with the lifting lever Nexus SeriesVeysel Kütüklü Nexus 3500
Automatic Bed Closing Machine 250 Pieces / 8 hours
Technical Specifications
Production Capacity
250 pcs/8 hours (90mm-190mm)
Bed Height
100 mm - 500 mm
Bed Size
60x120 cm, 200x210 cm
Stitching Speed (4mm pitch)
1600 mm (400 s.p.m), 1400 mm (3500 s.p.m)
Operating Temperature
0 °C - 40 °C
Energy Consumption
3 x 0.75 kw , 1 x 0.37 kw ,1 x 0.55 kw
Total Power Consumption
3.5 KW
Air Requirement
6 bar, 90 p.s.i.
Length x Width x Height
400 x 300 x 180 cm
Conveyor Height
95 cm
Machine Weight
1,250 kg.
Operating Voltage
Three phase 380 V, single phase 220 V,
50-60hz, Input fuse 25A, Cable 4x4 mm
Features
PLC-inverter Control and Touch control panel
Reinforced and robust construction needle cooling system
Automatic bed turning system
Adjustable corner program
Easy installation and short training time
Reinforced and precise sewing machine
Pneumatic sewing foot lifter
Production capacity of 250 pieces in 8 hours for each shift (bed edge closing)
With its flexibility and performance, it has a large or small bed production capacity.
High-quality machines that you can own at the most reasonable prices. The automatic bed turning feature reduces the operator's workload.
Outstanding Features
Nexus A100 is produced to accelerate the bed edge closing stitching process. With its ease of use, automatic slowing down in corners, and easy table height adjustment, it provides the best experience for bed edge closing operations while having an ergonomic structure, flexible and simple design.
Outstanding Features
