Advertisement No: | #00091325 |
Category: | Boring Machine |
Brand: | Mitsubishi |
Model Type: | MHT 11/1618 |
Product Type: | For Sale |
Product Status: | New |
Origin: | Other |
Location: | İsmetpaşa Mah. / Bayrampaşa / İstanbul |
Sales Detail: | Bank Transfer, Negotiated |
11/1250 | 11/1416 | 11/1618 | |
Spindle Diameter | 110mm | ||
Table Sizes | 1,250 x 1,250 mm | 1,400x 1,600 mm | 1,600x 1,800mm |
Table Indexing | Indexing at every 0.001 degrees | ||
Loading Capacity | 8kg (12 ops.) | 8kg (12 ops.) | 8kg (12 ops.) |
X Axis | 1,600mm | 2000mm | 2,000mm |
Y Axis | 1,500mm | 1,500mm | 2,000mm |
Z Axis | 1,100mm | 1,300mm | 1,300mm |
W Axis | 500mm | ||
Distance between Spindle End and Table Center | -150~1,450mm | ||
X,Y,Z Rapid Feed Rates | 12,000mm/min | ||
W Rapid Feed Rate | 6000mm/min | ||
B Rapid Feed Rate | 1000 degrees/min | ||
Cutting Feed Rate | 1~6,000mm/min | ||
Drilling Spindle Diameter | 110mm | ||
Drilling Spindle Taper | No.50 | ||
Pull – Stud | MAS I / MAS II | ||
Spindle Speed | 10~2,500 | ||
Spindle Motor Output | VAC11/15 kw (18.5/22 ops.) | ||
Tool Capacity | 40 (60- 80-120 ops.) | ||
Tool Selection | Tool pot number system (shortcut method) | ||
Max. Tool Length | 500mm | ||
Max. Tool Diameter | 110mm when neighbor tool exists - 300mm when no neighbor tool exists | ||
Max. Tool Weight | 30 kg | ||
Power Consumption | 48kVA (58-68-72-75 ops.) | ||
Machine Weight | 28,500kg | 30,900kg | 32,600kg |
Comes with Fanuc Control Unit and Standard Accessories.
