SM008-FA Full Automatic Cash Register Roll Machine

SM 008-FULLAUTO CASH REGISTER ROLL CUTTING MACHINE

                                     GENERAL FEATURES

• Full Automatic operation
• 10’’ control panel
• Hydraulic coil loading
• Hydraulic left-right adjustment
• Automatic paper tension control
• 2 Color flexo printing unit
• Banana roller to open the paper
• Automatic log removal
• Automatic paper compression
• Automatic cutting and gluing
• Automatic unloading
• Automatic spool filling
• Automatic breaking and pressing
• Automatic packaging and shrink
• 3 winding shafts diameter 15 mm

                                       TECHNICAL SPECIFICATIONS

· ELECTRICITY                                          :380V 50 HZ

· PRESSURE                                              :6 BAR min

· TOTAL POWER    MAX                       :35 KW

· MACHINE SPEED AVERAGE                             :200MT/MIN.

· CUTTING SIZE                                  :28-38-55-79 MM (4 SIZES)

· CORE DIAMETER OF THE COIL                           :76.2 MM

· COIL DIAMETER        MAX                       :1200 MM

· ROLLER LENGTH                              : 1100 MM

· MAX COIL LENGTH                              :1050 MM

· MACHINE DIMENSIONS    L*W*H              :1800*4750*1900

· WORKING AREA          L*W*H             :13000*8000*3500

· AVERAGE MACHINE WEIGHT                     :6.800 KG

MATERIALS AND THEIR PROPERTIES USED IN THE MACHINE

• AC electric motors            : Gamak,Volt or Elk
• Reducers                           : Yılmaz Reducer
• Servo Motors                     :Omron,xinje
• Planetary Reducers              :Kofon
• AC motor drivers              :Omron,xinje
• OEM electrical materials   :Omron,shıneder
• Hydraulic Group                         :Tekmak
• Pneumatic Group                      :Pnömax, tekmak,festo
• Brake Group                                :Unity
• Belt pulley group                  :8M Tos pulley,8M sun belt,band belts asya belt
•  Screw shaft and nuts          :G-Ten
• Machine body material      :40mm cnc machining
• Coil loading material     :30mm cnc machining
• Machine body color                 : Ral 7016
