15-60 Packs/Minute Fully Automatic Volumetric Packing Machine

Devpak Makina 5000 VLM

15-60 Packs/Minute Fully Automatic Volumetric Packing Machine

• Our serial and easy-to-use packaging machine, designed with a volumetric system, is equipped with the latest and superior technology and produces standard packages.

• Weight adjustment can be made easily by means of a geared motor.

• Thanks to the double pouring feature in the automation system, larger packages can be obtained without changing the cups.

• 5000 VLM  FEATURES

• - Sensitive serial packaging can be made between 10-5000 grams.

• - The jaw system is pneumatic or servo controlled and works in series.

• - Rubber pallet is used in the packaging pulling system and it does not damage the packaging.

• - It is possible to use packaging with or without photocell.

• - It has a numerator system that can automatically print production and expiration dates and whose dates can be changed easily.

• - The machine is PLC controlled and can work without errors and in series.

• - There is a touch screen on the machine.

• - Right-left adjustment of the packaging is easily done with a geared motor.

• - 304 stainless steel in accordance with the food regulations is used in the parts that come into contact with the product.

5000 VLM  TECHNICAL SPECIFICATION

• Packing speed: 15 - 60 packs / min

• Electric power: 380V-50 Hz

• Energy Consumption: 3.5 kw / hour

• Air Pressure: 8 bar

• Dimensions: Width 180 cm, Length 220 cm. Height 250cm
