| Advertisement No: | #00254123 |
| Category: | C Type Eccentric Press |
| Brand: | CronossTech |
| Model Type: | CEHP 160 |
| Product Type: | For Sale |
| Product Status: | New |
| Origin: | Turkey |
| Location: | İkitelli OSB Mah. / Başakşehir / İstanbul |
| Short Detail: | 2 Yıl Guaranteed |
| Sales Detail: | Negotiated |
| Delivery Status: | 90 Day |
Steel construction body Pneumatic clutch – brake system T channel additional extension plate 8 bearings ram Adjustable stroke on single crank arm Balancer piston on ram Full automatic fine lubrication system PLC control system Piano type control panel Touchscreen LCD display Motor reverse movement Overload hydraulic safety Motorized ram adjustment mechanism Photoelectric safety curtain Gear group in closed oil tank Double coil safety valve Compliance with CE standards Press feeding systems Waste material unloading systems Sliding safety cover in front of the table Mold with desired features Steel construction 8 slide monoblock body Vibration stress relief on body and welded parts Usable area with moving table: 1800 × 750 mm Usable area with fixed table: 1800 × 750 mm Parallelism and perpendicularity tolerances compliant with ISO and DIN standards Stroke distance: 200 mm (fixed) Table – Ram distance (max.): 500 mm Ram adjustment (regulation): 120 mm Eccentric shafts: CK4141 Gears: Steel cast Motorized table-ram distance adjustment Approximate press height: 4600 mm Approximate press width: 2700 mm Approximate press depth: 2200 mm Press lower table height from the ground: 900 mm Distance between walls: 2130 mm Press side window size can be adjusted as desired Flywheel bearing structure Slide bedding: Bronze (Zr14) Connecting rods, intermediate and main bearings: Bronze (Zr14) Central automatic grease lubrication Double crank structure Pneumatic clutch and brake combination system (Ompi) 4 ram cushioning cylinders Approximate press weight: 26,000 kg Main motor: 22 kW – IE3 Touch panel and PLC: Delta PLC program for mold adaptation to press Speed control device: Delta Operating speed: 25 – 45 strokes/min Mold recipe capacity: 100 pieces Switch gear materials: Siemens & Schneider Piano type or wall type electrical panel Table-ram distance measurement can be monitored on the screen This machine is manufactured by CronossTech in Turkey.H Type Eccentric Press – CEHP 160 Ton
Standard Features
Optional Features
Technical Specifications
Automation and Electrical Information
Production Information
