| Advertisement No: | #00254212 |
| Category: | Combined Scissors |
| Brand: | Cronosstech |
| Model Type: | KMH 85 |
| Product Type: | For Sale |
| Product Status: | New |
| Origin: | Turkey |
| Location: | İkitelli OSB Mah. / Başakşehir / İstanbul |
| Short Detail: | 1 Yıl Guaranteed |
| Sales Detail: | Negotiated |
| Delivery Status: | 45 Day |
Maximum thickness diameter: Ø 33 × 20 mm Diameter × thickness (Ø × t): Ø 57 × 12 mm Maximum diameter thickness: Ø 110 × 4 mm Stroke length: 80 mm Number of strokes: 25 Groove depth: 355 mm Working height: 1080 mm Round / Square: Ø 50 / 50 mm Vertical angle iron (90°): 150 × 150 × 15 mm Angled angle iron (45°): 80 × 8 mm Working height: 1200 mm Flat sheet: 380 × 20 mm Flat sheet: 480 × 15 mm Blade length: 482 mm Angled cut: 120 × 15 mm Working height: 940 mm Material thickness: 13 mm Width: 52 mm Depth: 100 mm Working height: 940 mm U–I profile blades (UPN–IPN): 160 × 74 mm T profile blades: 100 × 11 mm 100 × 100 × 13 mm Blade bending (max.): 250 × 20 mm Sheet bending (max.): 500 × 4 mm Jaw depth: 125 mm Sheet punching: Ø 38 × 10 mm Motor power: 7.5 kW Pressure: 85 tons Machine weight: 2315 kg Machine dimensions (W × D × H): 1920 × 950 × 2040 mm 2 separate hydraulic pistons and 2 separate foot controls allowing two people to work simultaneously Possibility of serial operation with adjustable piston stroke distance Central lubrication system Electric switchable rear support Working lamp On the same body, 5 separate workstations: Ø22 mm punch and die / standard hole drilling apparatus Full round and full square cutting blade set Angle iron cutting blade set Blade and sheet cutting blade set U-notching blade setKMH 85 – HYDRAULIC DOUBLE PISTON COMBINED SHEARS
STANDARD EQUIPMENT
PUNCHING DIE
FULL MATERIAL SHEAR
ANGLE IRON CUTTING SHEAR
SHEET METAL SHEAR (BLADE CUTTING)
NOTCHING
OPTIONAL EQUIPMENT
SPECIAL DIES
SPECIAL NOTCHING TOOL
V BENDING
PUNCH IN NOTCHING SECTION
TECHNICAL SPECIFICATIONS (KMH 85)
GENERAL EQUIPMENT AND STRUCTURE
