⌀229Mm 2950 Rpm Yüksek Basınçlı Salyangoz Fan
İlan No: | #00226754 |
Kategori: | Salyangoz Fan |
Marka: | Euroofan |
Model Tipi: | APEC 1001 |
Ürün Tipi: | Satılık |
Ürün Durumu: | Sıfır |
Menşei: | İtalya |
Teslim Durumu: | Stokta Var |
Konum: | Orta Mah. / Bayrampaşa / İstanbul |
Kısa Detay: | 1 Yıl Garantili |
Satış Detayı: | Havale / EFT, Görüşülür |
Satıcıyla iletişim kur
Euroofan APEC 1001
⌀229mm 2950 Rpm Yüksek Basınçlı Salyangoz Fan
For temperatures of the conveyed liquid from 90°C to higher than 350°C, a small heat-stop fan is threaded on the shaft between the support and the spiral; In addition, the fan is painted with special aluminum paint suitable for high temperatures.
.
ErP : These fans are within the scope of Directive 2009/125 / EC. This law does not apply in the following cases:
- Working in potentially explosive atmospheres (ATEX)
- Operation at high temperatures (fans designed with cooling fan)
- Operation at temperatures below -40°C
- Working in toxic, corrosive or corrosive environments (use of materials such as AISI 304, AISI 316, manganese steels).
These series are centrifugal forward curved fans and therefore Ntarget = 42 is expected (Reg. UE N.327 / 2011).
Efficiency IE2 motors conforming to IEC 60034-30 are taken into account in ErP calculations.
special rate> In the case of 1.11, please note that Directive 2009/125 / CE applies, but these fans are not subject to the energy efficiency restrictions imposed and thus the verification of these parameters.
Euroofan APEC 1001 Technical Specification
AIR FLOW | 26 – 60 m3/min |
INPUT PRESSURE | N/A – 1415 kg/m2 |
OUTPUT PRESSURE | 1530 – 1700 kg/m2 |
ENGINE BOARD | N/A – N/A poles |
INSTALLED POWER | N/A KW |
ROTATION SPEED | 2950 rpm |
SPEED LIMIT | 2950 rpm |
LIQUID TYPE | Clean, Dusty |
INLET FLANGE | ⌀229mm |
OUTLET FLANGE | 180x125mm |
WEIGHT WITHOUT MOTOR | 245 Kg |
SE 2 | 22 Kgm2 |
