Compack 5800İ Manuel Shrink Ambalaj Makinesi / COMPACK Series One Step Shrink Wrap Machines

İlan No : #00161936
Kategori: Manuel Shrink Makinası
Marka: Ultimate
Model Tipi: COMPACK 5800i
Ürün Tipi: Satılık
Ürün Durumu: Sıfır
Menşei: Türkiye
Teslim Durumu: Sipariş Üzerine
Konum: Atalar Mah. / Kartal / İstanbul
Kısa Detay: 1 Yıl Garantili
Satış Detayı: Havale / EFT, Kredi Kartı, Görüşülür
Fiyat Sorunuz
Min. Sipariş 1

Manuel Shrink Ambalaj Makinesi

COMPACK 5800i


Özellikleri:
- Küçük ve orta ölçekli işletmeler için pratik çözüm.
- Tek işlemde shrink sistemi, aynı anda hem kesme hem shrink işlemi.
- Farklı ürün yüksekliklerine göre ayar imkanı.
- Pratik film yerleştirme ve ayarlı taşıma mekanizması.
- Ayarlı paket besleme tablası.
- Seramik alaşımlı özel bıçak yatağı.
- Hava tahliyesi için filme delik delen aparatlar, 2 adet.
- Shrink için ısı ayarı (ayrıca ilave emniyet ısı kontrol sistemi).
- Tekerlekli pratik taşıma ayakları.
- Tek operatörlü sistem.
- Opsiyonel Manyetik çene kapalı tutma mekanizması ve zamanlayıcısı.
- ISO9001-2000 kalite belgeli üretim
- CE markası
- Yıpranabilen parçalar dışında 1 yıl garanti
- 5 yıl boyunca üretici firma garantisi altında yedek parça tedarik garantisi.


TEKNİK ÖZELLİKLER


Maksimum Kapasite: 5 - 10 paket/dk
Maksimum Rulo Çapı: Ø300mm Standart
Çalışma Yüksekliği: 860mm (8000-i Serisi 970 mm)
Uygulanan Film Türleri: POF: 7-37 mikron, PVC: 15 - 25 mikron
Maksimum Ürün Yüksekliği: 150mm (Opsiyonel: Yüksek Kabin)
Renk: Açık Gri RAL7035




COMPACK Series One Step Shrink Wrap Machines


Features:
- One Step Shrink System. Shrinks and seals simultaneously, only one operator required.
- Packaging solutions for small or medium volume of production.
- Digital panel in English and in other languages.
- Shrink temperature fine tuning in digital setting option.
- Solid state relays for longer life of electrical components
- Height adjustments for different heights of the products and adjustable production loading tray.
- Practical film roll placement and easy to slide film housing device.
- Ceramic blade housing, film perforator for optimal product appearance, standard legs, with casters for easy mobility.
- Magnetic holder (MG) for hood with timer control.
- ISO 9001 quality standard with the relevant norm’s confirmations.
- CE marking, guarantee for spare part stock and after sales support  and one year warranty on non-wearable parts

What is “Intelligent Sealing” system?

Blade temperature is normally varied and very often over heated due to the shorter or longer cycles with the fixed powered energy to the blade. Thus the mechanical contact points on the seal bar become weak. Due to the damages on the sealing system, sealing and packaging quality drops dramatically.

- Target temperature can be fixed. Depending on cycle time lengths, necessary power calculation is made automatically,
- Blade temperature can be fixed even in the first start-up cycle.
- With intelligent sealing system; the sealing power is fixed even if the cycle periods are varied
- Always the blade is powered as much as needed, potential operator mistakes will be avoided,
- Many times longer life time for rubber pad, teflon and ceramic,
- Smoke-free operation with blade temperature consistency, for operator health and environment.
- Improves packaging quality with better sealing and shrink performance
- Cosmetic quality of the sealing line will be perfect without burned black blade residues.

TECHNICAL SPECIFICATIONS

Maximum Capacity: 5 - 10 pack/min
Maximum Roll Diameter: Ø300mm Standard
Working Height: 860mm (8000-i Series 970mm)
Film Types: POF: 7-37 micron, PVC: 15 - 25 micron
Maximum Product Height: 150mm (Optionally Higher)
Color: Light Grey + RAL7035
