Paper Tube Making Machine

Fiyat Sorunuz
Min. Sipariş 1 Adet

İlan No : #00214800
Kategori: Mihver Makinesi
Marka: Sia Mekatronik
Model Tipi: S-KM001
Ürün Tipi: Satılık
Ürün Durumu: Sıfır
Menşei: Türkiye
Teslim Durumu: Stokta Var
Konum: Yeşiloba Mah. / Seyhan / Adana
Satış Detayı: Havale / EFT, Görüşülür

Satıcıyla iletişim kur

Sia Mekatronik

Sia Mekatronik Day. Tük. Mal. İnş. San. Tic. Ltd. Şti.

Danışman : Serhat A.

Sia Mekatronik

Paper Tube Making Machine

Minimum  Tube Diameter          8mm (ID)

Maximum Tube Diameter           600mm (OD)

Maximum Tube Wall Thickness  18mm

Minimum Cut to Length               150mm

Maximum Cut-to-Length             6000mm

Maximum Tube Cutting Speed 30 m/min

Maximum Number of Blades    10 units

Maximum Number of Layers     35 Pieces

This machine includes;

  1. Paper Bobin Stand
  2. Paper Glue Stand
  3. Pre Forming Stand
  4. Servo Cutting Stand
  5. Belt Conveyor Stand
  6. Color Painting Stand

For more information please contact with us via



PAPER BOBIN STAND

45 degree paper roll stand.

Max 5-50 layers, or customized the layers.

Paper roll distance 180 mm.

Paper roll center adapter.

Wheeled chassis.

Chassis fixing screwes.

PAPER GLUE STAND

Pneumatic glue pump 150 Lt/min.

Electrical glue pump 150 Lt/min.(Optional)

Electrical glue heater resistance with oil.(5 KW 3 phase)

Mechanic paper breake

Mechanic glue scraper

PRE FORMING STAND

[ URL HIDDEN ] 10 mm

Max diameter: 600 mm

Min-thickness: 0,5 mm

Max-thickness: 30 mm

Rewinding noses: Two noses single belt

Speed of adjust and control: Inverter

Power input: 3x380V



SERVO CUTTING STAND

6 Blades Pipe Cutting System with Servo

Cutting Motor: 0,75 Kw (6 Pieces)

Full Electronic Servo Controlled

Length Cutting System

Servo motor controlled blade cutting movement

Min: 130 mm Max: 6000 mm Cutting Length

Min: 0,5 mm Max: 15 mm Cutting Thickness

Min: 20 mm Max: 250 mm Inner Tube Drawing Feature

Smooth Cutting + - 2 mm

Production Speed Min: Max: 30 meters / minute

BELT CONEYOR STAND

Belt motor 0.37 kw.

Belt length 3000 mm.

Belt width 300 mm.

Belt motor with speed control

COLOR PAINTING STAND

1-Roll motor 0.37 kw.

2-Roll length 300 mm.

3-Printing width 300 mm.

4-Roll motor with speed control
