2 Stations 1 Color Tpu Injection Sole Machine
| İlan No: | #00231433 |
| Kategori: | Enjeksiyon Taban Makinası |
| Marka: | Permak Makina |
| Model Tipi: | T 312 |
| Ürün Tipi: | Satılık |
| Ürün Durumu: | Sıfır |
| Menşei: | Türkiye |
| Teslim Durumu: | Stokta Var |
| Konum: | Orta Mah. / Bayrampaşa / İstanbul |
| Satış Detayı: | Havale / EFT, Görüşülür |
Satıcıyla iletişim kur
Permak Makina
Permak Makina ve Kalıp San. Tic. Ltd. Şti.
Permak Makina T312
2 Stations 1 Color TPU Injection Sole Machine
|
2 STATION 1 COLOR INJECTION MACHINE FEATURES |
||
|
FEATURES |
VALUES |
MEASUREMENT UNIT |
|
Motor power |
37 |
K.W. |
|
Heater Capacity |
10.1 |
K.W. |
|
Total Electric Power |
47.1 |
K.W. |
|
Oil Tank Capacity |
360 |
L.T. |
|
Weight |
5 |
TON |
|
Most |
200 |
CM |
|
Size |
400 |
CM |
|
Height |
240 |
CM |
|
2 STATIONS 1 COLOR INJECTION UNIT INFORMATION |
||
|
FEATURES |
VALUES |
MEASUREMENT UNIT |
|
L/D Ratio |
20 |
MM |
|
Screw Diameter |
60 |
KG/CM 2 |
|
Injection Pressure |
1908 |
KG/CM 2 |
|
Injection Capacity |
663 |
CM 3 |
|
Injection Weight PS |
750 |
GR |
|
Injection Rate |
210 |
CM3/SN |
|
Plasticization Capacity |
97 |
KG/HR |
|
Screw Shaft Drive |
200 |
RPM |
|
2 STATION 1 COLOR INJECTION VISE INFORMATION |
||
|
FEATURES |
VALUES |
MEASUREMENT UNIT |
|
Kamapa Force |
150 - 200 (optional) |
TON |
|
Distance Between Columns |
420x450 |
MM |
|
Plate Size |
650x450 |
MM |
|
Opening Stroke |
300x350 |
MM |
|
Mold Binding Thickness (Max-Min) |
200 Max - 80 Min |
MM |
|
Goods Driving Force |
10 |
KN |
