20-5000 Gr Automatic Weighing Filling Packing Machine

Devpak Makina DEV 5000 TRP

20-5000 Gr Automatic Weighing Filling Packing Machine

• Our fully automatic scale packaging machines with the latest and superior technology equipment, serial and easy to use

• It is produced according to the needs of our customers as 2,3,4,6,8 and 12 scales.

• In addition, semi-automatic type with 1 or 2 scales  can also be manufactured.

DEV 5000 TRP FEATURES

- Sensitive serial packaging can be made between 20-5000 grams.

- It packs without damaging the product.

- The jaw system is mechanical and the speed adjustment is very easy.

- Rubber pallet is used in the packaging pulling system and it does not damage the packaging.

- It is possible to use packaging with or without photocell.

- It has a numerator system that can automatically print production and expiration dates and whose dates can be changed easily.

- The machine is PLC controlled and can work without errors and in series.

- The machine has an edge where the working speed and settings can be made.

- Right-left adjustment of the packaging is easily done with a geared motor.

- In the scale system, 304 stainless steel is used in accordance with the food regulations.

- Since the product receiving, weighing unit and packaging unit of the machine are separate from each other, the weight error is minimized.

GIANT 5000 TRP Technicial Specifications

- Packing speed: 15 - 40 packs / min

- Electric power: 380 V -50 Hz

- Energy Consumption: 3 kw / hour

- Air pressure: 6-8 bar

- Dimensions: Width 200 cm- Length 250 cm-Height 390 m
