40 Sheets / Minute (12Kw) Wafer Cream Application Machine

40 Sheets / Minute (12kW) Wafer Cream Application Machine

The Makren 40 Sheets / Minute Wafer Cream Application Machine is a high-efficiency solution designed to enhance wafer production processes. It applies liquid or aerated cream onto the wafer sheets coming from the cooling process, forming blocks. The machine begins by applying one layer of cream between two sheets, with the option to apply up to five layers of cream between a maximum of six sheets, resulting in 11-layered wafer blocks. The cream application is performed using a pneumatic system, and the cream can be applied in either single or double colors.

Key Features:

• Cream Application: The cream is applied to the wafer sheet using scraper blades mounted on a rotating drum.
• Recirculation System: Excess cream on the conveyor belt is collected into a stainless steel cream recirculation trolley, which pumps the cream back into the cream reservoir.
• Cylinder Pressing: The layered blocks are pressed using adjustable cylinders to evenly spread the cream between the wafers.
• Weight Control: An optional block weighing unit can be added after the cylinder pressing. Desired weight adjustments are easily tracked via the control screen.
• Optional Hazelnut Sprinkling Group: An additional hazelnut sprinkling unit can be added to the process.

Wafer Dimensions:

• The machine is suitable for wafers ranging in size from 290 x 470 mm to 350 x 500 mm. The conveyor tracks and belts can be adjusted to fit these sizes.

Machine Specifications:

• Cream Application Single Head: 40 sheets/min, Energy Consumption: 9 kW
• Cream Application Double Head: 40 sheets/min, Energy Consumption: 12 kW
• Cream Application Double Head with Hazelnut Sprinkling: 40 sheets/min, Energy Consumption: 12 kW
• Cream Recirculation Trolley: Energy Consumption: 6 kW
• Material: Made entirely from stainless steel
• Adjustable Layers: Suitable for applying a minimum of 2 and a maximum of 5 layers of cream.
• Automatic Adjustment: The machine automatically adjusts the number of layers, and the control panel allows for easy monitoring and adjustment.

Efficiency and Productivity
This machine provides a seamless and efficient cream application process, ensuring a smooth and continuous operation. The adjustable belts and tracks allow for flexibility in processing various wafer sizes. The pneumatic system ensures that cream is applied evenly and in the right quantities, improving product quality while reducing waste.

Hygiene and Durability
The entire machine is made from stainless steel, which guarantees a hygienic production environment and high durability. It is designed for long-term use with minimal maintenance, ensuring that your production line remains efficient and consistent.

Ideal for High-Speed Production
The Makren 40 Sheets / Minute Wafer Cream Application Machine is an excellent choice for businesses looking to increase speed and quality in wafer production. With its efficient cream application process, stainless steel construction, and customizable features, it ensures a smooth, continuous, and high-quality production process.

Payment Method in Turkey: 50% advance payment, 50% after loading.
