Nail Production Line

İlan No : #00177211
Kategori: Çivi Makinası
Marka: ERF Grup
Model Tipi: E-ÇH001
Ürün Tipi: Satılık
Ürün Durumu: İkinci El
Menşei: Türkiye
Teslim Durumu: 7 Gün
Konum: Mehmetakif Mah. / Küçükçekmece / İstanbul
Kısa Detay: 2 Yıl Garantili
Satış Detayı: Havale / EFT
Fiyat Sorunuz

Erf Grup  Nail Production Line









ORDER

PIECE

PRODUCT CODE

1

1

 5 STATIONS FOR WIRE PREPARATION BEFORE PRODUCING NAILS  TUNCA BRAND MADE IN TURKEY

2



6 TON WIRE DRAWING CAPACITY IN 10 HOURS

3





4

1

WIRE UNLOADER COILER

5

26

WIRE PULLING PULLEY

6





7

4

6 CM NAIL MACHINE -    320 PIECES /  1,060 KG PER MINUTE (6 cm nail machine can produce a nail of 3.5 mm thickness with 60 mm length / long)

8

3

8 CM NAIL MACHINE -     260 PIECES / 1,680 KG PER MINUTE (8 cm nail machine can produce a nail of 3.5 mm thickness with 80 mm length / long)

9

3

10 CM NAIL MACHINE -  225 PIECES  / 2,570 KG  PER MINUTE (10 cm nail machine can produce a nail of 4 mm thickness with 100 mm length / long)

10





11

1

2500 KG NAIL DEGREASING AND POLISHING MACHINE

12

1

1000 KG NAIL DEGREASING AND POLISHING MACHINE

13





14

1

BOX PACKING MACHINE

15





16

1

1500 KG  WEIGHING MACHINE

17

1

150KG  WEIGHING MACHINE

18





19

1

COMPRESSOR

20

1

WELDING MACHINE (WIRE END CONNECTION/JOINTS)

21

1

GRINDING MACHINE

22

1

DRILL

23

1

SHARPENING MACHINE

24

1

VERTICAL DRILL

25





26

1

FORKLİFT BUCKET

27

1

2020 MODEL 3500 TONNE  FOKLİFT

28

1

3 ton pallet truck











RAW MATERIALS TO BE USED IN NAIL PRODUCTION

31

6 TON

WIRE ROD IRON 1008-5.5MM RAW MATERIAL





33

200 KG

MILL SOAP     200 KG

34

20

Rolling Forms 30 ADET

35

2 roll

shrink film 55CM 70MİC.  For packaging













































NAIL MACHINES BRANDS:





                                                   *   2 MACHINES ÜSTÜN BRAND





                                                   *   1 MACHINE WAFIOS  BRAND





                                                   *   2 MACHINES BOZKURT BRAND





                                                   *   4 MACHINES TUNCA BRAND





                                                   *   1 MACHINE AHMET RIZA KAYA BRAND

















800 M2 WORKPLACE, MUST BE STRAIGHT ENTRANCE





100 KW TRIPHASE ELECTRIC LINE





IF THERE IS A POWER INTERRUPTION, YOU SHOULD HAVE A 100KW GENERATOR.
