İlan No: | #00185120 |
Kategori: | İlaç Dolum Makinası |
Ürün Tipi: | Satılık |
Ürün Durumu: | Sıfır |
• Advanced easy-to-use Beckhoff PLC control system
• Touch screen 7" or 15" operator panel
• Motor-controlled weight adjustment from the operator panel
• Pneumatic suction and discharge
• Tri-Clamp quick connect
• Scada Display
• Unlimited Recipes
• Remote Access, Access and interfere with machine screens from your computer or follow production quantities.
• Input Full, Output Full and all sensors in the machine report on the screen in case of an error
• Door with safety contact and emergency stop
• Low electricity consumption and quiet operation thanks to variable conveyor speed
• Thanks to analog cards, all controls are on the screen.
• Sensors used on the machine (such as photocell) SICK, KEYENCE
• Pneumatic materials used on the machine SMC, FESTO
• All reducers used on the machine are Bonfiglioli / Yılmaz Gearbox
• All 304 and 316 stainless materials used on the machine are licensed.
• Easy change in a short time
• Ease of maintenance and service
• Closed enclosure in CE norms to ensure occupational safety and environmental cleanliness
Technicial Specifications
System: Rotary
Working Principle: Volumetric
All surfaces in contact with the construction and product are AISI 316, other visible surfaces are 304 quality stainless steel
Control Unit: Beckhoff
Filling tank: 150lt (with sensitive level control)
Packaging: Plastic, glass, metal
Cylinder: Shot brand glass or AISI 316
Weight range: set on the screen
Filling Accuracy: ± 0.3%
Electricity Requirement: 380V 50Hz 3 Phase
Air Requirement: 6-8 Bar
Energy Consumption: 3.5 kW
Air Consumption: 600 lt/min
Weight: ~1.750kg
Capacity: Pixels by bottle formula and virtual viruses.
