STP 400 TKM 40 Cm Fusing Machines

İlan No : #00188739
Kategori: 40 cm Tela Presi
Marka: MCN Saben
Model Tipi: STP 400 TKM
Ürün Tipi: Satılık
Ürün Durumu: Sıfır
Menşei: Türkiye
Teslim Durumu: Stokta Var
Konum: Yenibosna (Merkez) Mah. / Bahçelievler / İstanbul
Satış Detayı: Takas Olur, Vade Olur, Leasing'e Uygun, Kredi Kartına Taksit, Çekle Şatış, Havale / EFT, Kredi Kartı, Krediye Uygun, Hibe Destekli Ürün, Kosgeb Destekli
Fiyat Sorunuz
Min. Sipariş 1 Adet

MCN Machine STP 400 TKM

40 Cm Fusing Machines



It is used for fusing and ironing in the ready-made clothing industry. Its area of application generally relates to the smooth and rapid fusing of continuous interlining fused on the trouser waistbands. Winding is possible at 4 or 5 controlled speeds depending on the machine width. It is equipped with a nonslip tape control system and the pneumatic pressure offers a better quality fusing. The special splicing tapes used in our machines eliminates the trace problem on the product worked and doubles the tape lifetime. Tape width varies between 40 cm and 60 cm depending on models. Our machines are equipped with two resistance groups; i.e., upper and lower resistance systems. Precise heat adjustment is possible by means of the electronic thermostat. Tape is cleaned and fused products are taken by means of the rotary silicone scrapers of machines

MCN Machine STP 400 TKM Technical Specification



TECHNICAL CHARACTERISTICS

STP 400 TKM

STP 600 TKM

RESISTANCE POWER 5 KW 7 KW
FUSING DURATION 5 – 30 SEC 5 – 30 SEC
PRESSURE 0 – 6 KG 0 – 6 KG
MAX TEMPERATURE 0 – 200 °C 0 – 200 °C
MAX TAPE SPEED 0 – 10 m/min 0 – 10 m/min
VOLTAGE 380V AC 50 HZ 380V AC 50 HZ
DIMENSIONS 90 x 290 x 140 cm 110 x 290 x 140 cm
WEIGHT 287 kg 335 kg
