20 000 M3 / Hours Dust Collection System Jet Pulse Filter

JET PULSE CARTRIDGE FILTER

Jet pulse cartridge filters are used in businesses with low dust density. The dusty air sucked from the source by means of the fan and the installation is sent to the jet pulse filtering unit. The important thing here is to transport the dust from its source and at appropriate speeds to the filtering unit with piping. The dust whose speed is slowed down is kept in cartridge type filters selected according to the process. In order to extend the life of the cartridge filters, special deceleration equipment should be installed in the system. The dust coming into the cartridges at low speed will not wear out the cartridges and prolong the life of the bags.

Contaminated cartridges are cleaned by instantaneous blowing of 6-7 bar air into the cartridges by the valves connected to the time control unit. Since the cartridges are attached to the device body, they do not fall or explode. The dust particles falling by the shocking means fall into the bunker at the bottom of the filter. Optionally, the dust is discharged into big bags by the operator or automatically. Before and after cleaning, the fan is not affected by dust and throws the clean air that meets the emission measurement standards into the atmosphere. Since jet pulse cartridge filters save space for businesses with low dust density, these businesses always prefer Bunkar Makina.

Usage areas of jet pulse cartridge filters; sectors such as food, medicine, chemistry, plastic, metal, paint, ceramic industry, cement, mining, defense industry, wood industry. It is especially preferred in these sectors. These filters actually perform the same function as the bag filters, which are among the dust collection systems. Only cartridges are used as filtration material instead of bags.

Depending on the type and structure of the powder, there are varieties with different properties. Compared to bag filters, the filtration surface areas per unit are much higher. This is an important reason why it is often preferred. It is very important to choose the right cartridge according to the type, structure and prominent features of the powder. Because when choosing the wrong cartridge, you may encounter negative situations or cause the filter to work incorrectly. Therefore, choosing the appropriate cartridge filter is of great importance. Jet purse cartridge filters, which are designed and manufactured to be used in dry and oil-free industrial factories, are among the filters commonly used by many businesses. As Bunkar Makina, we choose the right devices according to the dust density in the filter. In addition, the fan and suction adapters are measured by our expert team.

As Bunkar Makina, we choose the right devices according to the dust density in the filter. In addition, the fan and suction adapters are measured by our expert team. As Bunkar Makina, we choose the right devices according to the dust density in the filter. In addition, the fan and suction adapters are measured by our expert team.

JET PULSE CARTRIDGE FILTER FEATURES

Jet pulse cartridge filters, which are frequently preferred in industrial areas, have many important features. Its general features include a capacity range of 1.000-50,000 m3/h, special design according to the process, namely flexibility, 99.5% regional dedusting, fast and simple maintenance, self-cleaning feature, pulse system, emission values ​​in Environmental Legislation at the filter outlet, bucket or bigbag and dust discharge, automatic filter cleaning with different pressure measurement, easy and fast filter change thanks to its hinged front covers. It draws attention especially with its high energy efficiency and long-lasting use. These filters, also known as pulse cartridges, are mostly used in central system dust particles removal and smoke extraction applications. Using the cartridge filter, Required purification from dust originating from industrial production is provided to a large extent. Generally, self-flange round ducts are preferred to purify the environment from dust.

Choosing the right cartridge filter is very important in the use of jet pulse cartridge filters. Choosing a wrong filter will not only cause the device to fail, but also cause the filter to wear out and become unusable. Since sparks, abrasive or abrasive parts that may come to the filter during the applied process fall into the collection bucket at the bottom of the bunker, the filters are protected and thus their usage time is extended. Bunkar Makina dust collection units take up very little space thanks to their design. All necessary accessories are the devices on it. It can be used immediately as assembled in one piece, or it can be disassembled in three pieces optionally. The devices are both robust and quite economical. Although they are very simple to use, they work extremely quietly. Jet pulse cartridge filter devices are specially designed and manufactured. For this reason, it cleans the air of your business without creating sound pollution. In addition, thanks to the self-cleaning system, the compressed air consumption is minimized and the filter life is extended. These devices, which attract attention with their easy maintenance, are still preferred in many industrial areas.

Jet pulse cartridge filters have some accessories. These accessories are; pulse valve and air tube, centrifugal fan, fan control panel, differential pressure controlled solenoid driver and dust bucket. Some optional accessories are also available. Optional accessories include explosion cover, pilot box, silencer and compressed air regulator. All these accessories are used during filter application. With its expert team and special filter designs, Bunkar Makina is preferred by many industrial enterprises. You can easily reach us through our contact information about the usage, usage areas, features and more of jet pulse cartridge filters.
